Siglent SDS1000X-E Series
DPO Fast Phosphor Oscilloscope

  • Interface: LAN, USB 2.0, USB2
  • OS: Win

Fast Signal Analysis DPO Oscilloscope


SIGLENT’s DPO offering supports multiple powerful triggering modes including serial bus triggering. Serial bus decoding for IIC, SPI, UART, CAN, LIN bus types is included. The series also include History waveform recording, and sequential triggering that enable extended waveform recording and analysis. Another powerful addition is the new 1 million point FFT math function that gives the SDS1000X-E very high frequency resolution when observing signal spectra.

- Up to 200 MHz bandwidth
- Waveform capture rate up to 400.000 wfm/s (sequence mode)
- Real-time sampling rate up to 1 GSa/s
- Record length up to 14 Mpts, 1 Mpts FFT
- WiFi control (optional on 4 channel only)

ModelBandwidthChannels
SDS1202X-E
2002+EXT
SDS1104X-E
1004
SDS1204X-E
2004

What's included

  • SDS1000X-E unit
  • USB Cable
  • Quick Start Guide
  • 4 x Passive Probes
  • Certification
  • Power Cord

Siglent SDS1000X-E Series
DPO Fast Phosphor Oscilloscope

  • Interface: LAN, USB 2.0, USB2
  • OS: Win

art : SDS1202X-E
€ 339 excl. VAT
€ 424 incl. VAT

My AutoQuote | Easy & Fast

Easily generate and keep track of your quotes. You can also place an order based on an active quote. Both Quotes and Orders are organized for you under your account page.

More information

Specifications

ACQUIRE SYSTEM
Sampling Rate1 GSa/s (single channel/pair), 500 MSa/s (two channels/pair)
Memory DepthMax 14 Mpts/Ch (single channel/pair), 7 Mpts/Ch (two channels/pair)
AverageAverages:4, 16, 32, 64, 128, 256, 512,1024
INPUT
Channels2-4
ImpedanceDC: (1 MΩ±2%) || (15 pF ±2 pF) (Four channel series)
Max Input voltage1 MΩ ≤400 Vpk(DC + Peak AC <=10 kHz)

Product information

Power Loop Response AnalysisStability is a very important indicator in power supply design. In general, stability measurement requires a special frequency response analyzer, but it is very expensive. Siglent offers an affordable solution: SDS1000X-E oscilloscope and signal source Power loop measurement with standard Free Bode Plot II software.
  • Higher measurement sensitivity and accuracy
  • Variable excitation scan mode allowed for complex test scenarios of the power control loop test box
  • User-friendly UI design
  • List and cursor measurements, more intuitive
Deep Memory Depth - High Capture Rate
  • Digital trigger system, high trigger sensitivity and low jitter 256-level
  • Intensity Grading and Color Temperature
  • Display With a waveform capture rate of up to 400,000 wfm/s (sequence mode), the oscilloscope can easily capture the transients or low-probability events.
  • Using max record length of up to 14 Mpts, users are able to oversample to capture for longer time periods at higher resolution
Revolution in Data Analysis Processing
  • True fast measurement and math to all of 14M sample points so that there is minimal distortion on analysis
  • With hardware co-processor, faster data operations
  • 1 M point FFT operation
  • Support Zoom, Gating, Math measurement and statistics
  • Support 38 automatic measurement functions
Standard Serial DecodingMost oscilloscopes on the market do not offer serial decoding for free but SDS1000X-E does. Serial decoding is free and includes IIC, SPI, UART, CAN, and LIN.
The waveform and data can be displayed at the same time and the detailed decoding information is displayed in the form of a list, and the data can be stored and exported.
Powerful Debugging and Analysis Capabilities
  • Event search and navigation to quickly locate events of interest
  • MSO logic analyzer integration, mixed signal analysis too
  • The combination of history and sequence mode, quickly capture abnormal waveforms
  • Hardware-based Pass/Fail mode for long-term monitoring signals

Remote Control via Web Pages

With built-in Web Server, there is no need to install driver software and PC software. You can control the instrument, observe waveforms, obtain measurement results using the browser remotely.  Especially when instruments used in high pressure, high temperature and other special environments. The SDS1000X-E supports both web and mobile web layouts, making it easier to control the instrument even on your phone.
